Basic Info.
Model NO.
GKA120M 590W
Number of Cells
120PCS
Application
Industrial
Condition
New
Certification
EST, ISO, CB, CE, FCC, RoHS TUV
Material
Monocrystalline Silicon
Size
2172X1303X35mm
Cell
210*105mm
Junction Box
IP 67 Rated
Module Efficiency (%)
20.85%
Transport Package
Wooden Pallet
Specification
580w
Trademark
GAMKO
Origin
China
HS Code
8541402000
Production Capacity
1000000PCS/Month
Packaging & Delivery
Package Size
232.20cm * 128.40cm * 123.00cm
Package Gross Weight
744.000kg
Product Description
GK120M 330W
BIFACIAL MODULE
BIFACIAL MODULE
Passionately committed to
delivering innovative energy solution
ADVANCED PERFORMANCE & PROVEN ADVANTAGES
delivering innovative energy solution
ADVANCED PERFORMANCE & PROVEN ADVANTAGES
1. High module conversion efficiency up to 19.77% by using Passivated Emmiter Rear
Contact (PERC) technology.
2. Low degradation and excellent performance under high temperature and low light
conditions.
3. Robust aluminum frame ensures the modules to withstand wind loads up to 2400Pa
and snow loads up to 5400Pa.
4. High reliability against extreme environmental conditions (passing salt mist,
ammonia and hail tests).
5. Potential induced degradation (PID) resistance.
6. Positive power tolerance of 0 ~ +3 %.
| ELECTRICAL CHARACTERISTICS AT NOCT Nominal Power (P ) | 222W | 229W | 233W | 237W | 241W | 244W | 248W | 252W | ||||||||||||||||||||||||||||
| Open Circuit Voltage (V ) | 36.4V | 36.8V | 37.0V | 37.3V | 37.5V | 37.6V | 37.8V | 38.0V | ||||||||||||||||||||||||||||
| Short Circuit Current (I OC) | 7.84A | 8.00A | 8.08A | 8.16A | 8.24A | 8.34A | 8.41A | 8.49A | ||||||||||||||||||||||||||||
| Voltage at Nominal PowSCer (V ) | 29.5V | 29.9V | 30.1V | 30.3V | 30.5V | 30.6V | 30.7V | 30.9V | ||||||||||||||||||||||||||||
| mp Current at Nominal Power (I ) | 7.50A | 7.66A | 7.73A | 7.81A | 7.88A | 7.98A | 8.05A | 8.12A | ||||||||||||||||||||||||||||
| mp | ||||||||||||||||||||||||||||||||||||
CERTIFICATIONS
1.IEC61215, IEC61730, IEC62716, IEC61701, CE, CQC, CGC, ETL(USA),
JET(Japan), J-PEC(Japan), Kemco(South Korea), KS(South Korea), MCS(UK),
CEC(Australia), FSEC(FL-USA), CSI Eligible(CA-USA), Israel Electric(Israel),
InMetro(Brazil), TSE(Turkey)
2. ISO9001:2008: Quality management system
3. ISO14001:2004: Environmental management system
4. OHSAS18001:2007: Occupational health and safety management system
| TEMPERATURE CHARACTERISTICS Nominal Operating Cell Temperature (NOCT) 45°C±2°C | ||||||||||||||||||||
| Temperature Coefficients of P | -0.37%/ºC | |||||||||||||||||||
| max Temperature Coefficients of V | -0.28%/ºC | |||||||||||||||||||
| OC Temperature Coefficients of I | 0.048%/ºC | |||||||||||||||||||
SPECIAL WARRANTY
1. 12 years limited product warranty.
2. 30 years Limited linear power warranty
2. 30 years Limited linear power warranty
